Charles McMurray Co. 2021 Catalog

1333 / 1590

Hybrid Brackets
Surface or Concealed Mounting
• Surface or concealed mounting for floating shelf appearance
• Texture powder-coated finish in black or white
• Non-handed
• Vertical tubular arm: 1-1/2" (width) x 3/4" (thickness)
• Horizontal arm (T-shape): 1-1/2" x 1-1/2"
• Multiple mounting holes on support arm and vertical tube
• Includes plastic finishing caps for tube and screw holes
• Mounting hardware not included
Item No.
(A)
Arm
(B)
Height Finish
Load Rating
(per pair) List Ea.
List Ea.
2
List Ea.
10
12" 12" Black 2,050 $108.22 $97.74 $81.90
12" 12" White 2,050 $94.68 $86.58 $73.90
18" 18" Black 1,780 $148.78 $134.38 $112.60
18" 18" White 1,780 $148.78 $134.38 $112.60
24" 24" Black 1,360 $164.88 $150.74 $128.68
24" 24" White 1,360 $188.42 $170.20 $142.60
Surface Mounting Concealed Mounting
Dimensions
Drywalled
Concealed applications require ripping
a 2"x4" lengthwise, and mounting the
ripped 2"x4" 2 to the side of a standard
2"x4" 1 stud. Bracket is then mounted
to the recessed (ripped) 2"x4".
Install drywall around support arm.
Mounting Detail
1
2
1
Plastic finishing caps to conceal
the bottom of the tube
and the screw holes
are included.
1
2
Finishing Caps
2
