Charles McMurray Co. 2021 Catalog

1296 / 1590

Prep 104: End and center
screwhole preps for out-swing
sills. 3 holes each end. One
center hole for lengths up to
49-1/2", 2 center holes for
lengths over 49-1/2".
width A
5/8"
5/8" 2-1/4"
width B
4 degree bevel
width A
5/8"
5/8" 2-7/8"
width B
4 degree bevel
Out-Swing Sills
Polybagged, sold per each.
Item No.
Width
A
Net
Length
Width
B Box List Ea.
Aluminum
4-7/8" 37-1/2" 2-5/8" 20 $57.12
4-7/8" 74" 2-5/8" 5 $106.86
5-5/8" 37-1/2" 3-3/8" 20 $60.02
5-5/8" 74" 3-3/8" 5 $112.54
6-5/8" 37-1/2" 4-3/8" 20 $62.94
6-5/8" 74" 4-3/8" 5 $118.22
Bronze
4-7/8" 37-1/2" 2-5/8" 20 $71.70
4-7/8" 74" 2-5/8" 5 $135.26
5-5/8" 37-1/2" 3-3/8" 20 $77.52
5-5/8" 74" 3-3/8" 5 $146.62
6-5/8" 37-1/2" 4-3/8" 20 $83.36
6-5/8" 74" 4-3/8" 5 $157.98
Rubber Ramp Assembly
• Made from 100% recycled rubber tires - 20 mesh minus crumb
reclaimed rubber with urethane binders
• Enhanced skid resistance with the exclusive diamond waffle
pattern
• Can be field cut and coped using ordinary tools
• Trim to fit just about any door entry
• Can be ripped for offsets less than 1-1/4"
• Plane bottom surface of ramp to accommodate irregular
surface conditions
• No need for miter returns since they are molded into the
design of the ramp
Use a silicone adhesive when installing.
Item No. Box List Ea.
10 $306.04
Meets or exceeds the following requirements:
• UL410, ASTM D 2047, Federal Specifications P-F-430C
• ANSI A117.1-2013
• UL Standard 410 Slip Resistance of Floor Materials
NOTE: Pemko recommends using
only silicone if being glued.
Polybagged, sold per each.
Item No.
Width
A
Net
Length
Width
B Box List Ea.
Aluminum
CESO64A3712 6-5/8" 37-1/2" 3-3/4" 20 $62.94
CESO64A74 6-5/8" 74" 3-3/4" 5 $118.22
Bronze
CESO64D3712 6-5/8" 37-1/2" 3-3/4" 20 $83.36
CESO64D74 6-5/8" 74" 3-3/4" 5 $157.98
For 1-3/8" Doors
For 1-3/4" Doors
Designed for a 1-3/8" door. They can be used for a 1-3/4" door,
however, the drip will not extend to cover stucco or 5/8" siding.
DOOR
HARDWARE
TOOLS FASTENERS SHOP &
FINISHING
ABRASIVES LACQUERS &
FINISHES
ADHESIVES FURNITURE
HARDWARE
EDGING &
DECOR.WOOD
SHELF &CLOSET
ORGANIZERSKITCH./BATH
LIGHTING SLIDES
DOORS &DRAWERS
LOCKS &CATCHES
AVENTOS &
LIFTS
CABINETHINGES
DECORATIVEHARDWARE
DOOR LOCKS & HARDWARE
800.533.0533 2021 1946 1296 Prices subject to change without notice.
