Grade 2 Light Commercial Locksets
Kingston Lever x Lever (KNL)
Satin Chrome finish.
Item No. Function Case List Ea.
Passage 12 $59.10
Privacy 12 $63.10
Storeroom* (Vestibule) 20 $91.80
Half Dummy 20 $29.60
Entry 12 $88.80
*Outside lever always locked, inside lever not locking.
Door Prep: Crossbore 2-1/8", Edge Bore 1"
Backset: Adjustable to 2-3/8" or 2-3/4"
Door: 1-3/8" to 1-3/4"
Faceplate: 1" x 2-1/4", radius corner
Strike: 2-1/4" full lip, radius corner
Cylinder: SmartKey or Pin & Tumbler
ANSI/BHMA: Grade 2
3-7/8"
2"
7/16"
2-35/64"
NOTES:
For latches and strikes see catalog page 1247.
Prices shown are Kwikset's List Prices from
July 2022 Box Pack Price Guide.
Kingston Interconnect
Metal Interconnect
Passage Interior
Cylinder: SmartKey
Faceplate: Complete locksets: UL 3028, 3031, (WFL option 3846)
1” round corner, 1” square corner, 1-1/8" WFL square
Interior assemblies: determined by handleset ordered
Strikes: Complete locksets: UL 3028 std. - 3031 opt. (WFL option 3846)
Deadbolt Strike: UL 5278, 3223 opt. (WFL 4632 opt.)
Interior assemblies: determined by handleset ordered
Handing: Reversible
ANSI/BHMA: A156.12, Grade 3
ADA: All lever options meets 4.12.9 ADA requirements
UL: Meets 3 hour fire rating for all UL functions
Finishes
26D = Satin Chrome
Interior Trim Specifications
Entry Interior
Entry Exterior
A simple turn of the interior lever opens both deadbolt and latch at
the same time in an emergency exit. Single cylinder deadbolt oper-
ated by key outside and thumbturn inside. Entry has keyed deadbolt
and keyed lever. Passage has keyed deadbolt and passage lever.
Door Prep: Crossbore 2-1/8” Edge Bore 1”
5-1/2” center-to-center
Backset: Complete locksets: 2-3/8” sq UL standard
Door Thickness: 1-3/8" - 1-3/4”
Box Pack - 6 per case. Satin Chrome finish.
Item No. Description List Ea.
Entry-Kingston $269.60
Passage-Kingston $252.30
Style A B C D E F
Kingston 1-7/16" 2-15/32" 5-1/2" 2-53/64" 10" 2-31/32"
