Charles McMurray Co. 2021 Catalog

1191 / 1590

JOBSITE SAW PRO
Item No.
Horse
Power Voltage Retail Price
1.5 120 $1,579.00
Prices shown are SawStop's Retail Prices. Discounts not available on SawStop retail prices.
Saw Dimensions Saw Dimensions with Cart Table Dimensions
(Extended) Width 31-3/4" Width 48"
Depth 28-3/4" Depth 29" Width 43-5/16"
Height 15-1/2" Height 36" Depth 24-5/8"
Includes
1 Collapsible Rolling Cart 1 10" Blade
1 Miter Gauge 1 Standard Brake Cartridge
1 JSS Active Dust Collection Blade Guard 1 User’s Guide
1 Riving Knife 1 Hardware Pack
2 Blade Wrenches 3 Hex Keys (3mm, 4mm, 5mm)
1 Push Stick 1 Assembly Instructions Poster
1 High/Low T-Style Fence w/Ergolock
Specifications
Motor Configuration 120 VAC 60 Hz, Universal
Amperage 15A
Motor Peak HP 4
Motor Continuous HP 1.5
No Load RPM 4,000
Blade Diameter 10"
Dado Diameter 8"
Max. Depth of Cut, Blade at 0° 3-1/8"
Max. Depth of Cut, Blade at 45° 2-1/8"
Max. Rip Right of Blade-Extended 25-1/2"
Dado Max. Width 13/16"
Bevel Angle Range -1 to 46
Cord Length 116"
Weight - Saw Only 84 lbs.
Weight - With Cart 113 lbs.
• Ultimate portability: 113 lbs. with included cart
• One-turn elevation system raises or lowers the blade quickly
• QuickTilt tilts the blade easily and quickly
• ErgoLock T-Style Fence slides smoothly and locks firm
• Superior dust collection
• Powder-coated aluminum table
• On-board accessory storage drawer
One-Turn Elevation
Ground-breaking elevation sys-
temraises or lowers the blade in
just one turn of the handwheel.
QuickTilt
Tilt the blade easily and quickly
to your ideal angle in 1 degree
increments. Fine tune between
degrees with the Tilt Adjust.
T-Style High/Low Fence with Ergolock
The T-Glide Fence slides smoothly and locks
firm with the innovative ErgoLock. The T-style
design squares on lock-down to increase
accuracy. Extend the OnDemand Shelf for
support when needed.
Advanced Dust Collection
The included Active Dust Collection Blade
Guard protects against kickback and uses
blade turbulence to collect above-table
dust.Under-tableshroudingmaximizesdust
extraction for a cleaner, safer work area.
