Charles McMurray Co. 2021 Catalog

1122 / 1590

Features & Benefits:
• Ideal for finish and trim work
• Ultra-quiet 68 dBZ
• Ultra-light 20 lbs.
• Heavy-duty induction motor
Specifications
Height 13"
Length 14"
Width 10"
Tool Weight 20 lbs.
Current Draw/Max AMPs 4 amps@115V
Horsepower 0.5
Pump Oil free
SCFM at 90 psi 0.7
Max Pressure 125 psi
Pump Up Time 128 seconds (0-125 psi)
Recovery Time 35 seconds (90-125 psi)
Tank Storage 1 gallon
No.
1/2 hp Finish & Trim Electric Compressor
• 1 HP (rated/running), 2 HP (peak)
• 2 gallon aluminum (rust-free) tank
• 3.10 CFM @ 40 PSI, 2.20 CFM @ 90 PSI
• 120 PSI maximum
• Powerful 1.0 HP motor operates at only 1680 RPM
creating less noise and less wear
• Oil-free dual piston pump system is engineered for high
performance and durability
Features:
• Two pressure control gauges
• One universal 1/4" quick connector
• 120 PSI maximum pressure
• 110v / 60 hz - 8.5 Amps
• Tank fill rate 50 seconds
• Oil-free dual piston pump designed to have a life cycle of
3000+ hours
• UL Certified
No.
1 hp 2 Gallon Air Compressor
Ultra Quiet !
• 2 HP (rated/running)
• 4.6 gallon aluminum (rust-free) twin tank
• 6.40 CFM @ 40 PSI, 5.30 CFM @ 90 PSI
• 2.0 HP motor operates at only 1680 RPM creating
less noise and less wear
• Oil-free dual piston pump system is engineered for high
performance and durability
• Easy start valve for less starting amperage
Features:
• Two pressure control gauges
• Two universal 1/4" quick connectors
• 125 PSI maximum pressure
• 110v / 60 hz
• Low amp draw - only 14.0 Amps
• Oil-free dual piston pump designed to have a life cycle of
3000+ hours
No.
2 hp 4.6 Gallon Air Compressor
Length: 18-11/16"
Width: 14-3/16"
Height: 13-1/2"
Weight: 35.3 lbs.
Length: 19-3/32"
Width: 16-11/16"
Height: 19-11/16"
Weight: 64 lbs.
